APX 101- FIXED WINDOW

APX 101 Fixed / Direct Set Series is built around a sleek, minimal aluminum frame that puts the focus on glass and unobstructed views. Engineered for large-format openings, it delivers expansive daylight and clean architectural lines while maintaining structural integrity and performance. It’s a pure, modern solution designed to frame the view—nothing more, nothing less.

Material

Thermally broken aluminum

Finish

AAMA 2604 Powder coating

Glass

Offered in Dual and Triple pane

Sizing

Max: 96 Sqf

APX 101 Fixed window

The Details

Integrated casement hardware

Exterior is made with extruded aluminum for proven strength and versatility

Hidden drainage system

Unique wash mode allows access to both sides of glass from indoors

Retractable screen option

Unique wash mode allows access to both sides of glass from indoors

Dual or triple pane glass

Ogee and Ovolo sticking has a more traditional profile and square sticking has a more contemporary look

Product Overview:

The APX 101 Fixed Window is designed to deliver expansive views through a narrow, refined aluminum profile that emphasizes clean architectural lines and maximum glass. Engineered to pair seamlessly with our casement and tilt & turn window systems, as well as our door platforms, the APX 101 creates a cohesive look across the entire ARC product lineup.

Built with a thermally broken aluminum frame and boot-glazed construction, the APX 101 is designed for long-term performance, durability, and energy efficiency. Its minimalist design allows it to serve as the perfect companion to operable windows, or as a standalone solution for large, fixed openings where uninterrupted views and modern aesthetics are the priority.

Design Options

Size Specifications

Finishes

Our aluminum products feature a durable AAMA 2604 powder coat finish, delivering long-lasting color performance and resistance to fading, chalking, and weathering. Choose from over 25 standard colors, with the flexibility to create custom color options at no additional cost, allowing you to perfectly match the design vision of any project.

Glass

All ARC products come standard with tempered safety glass for enhanced strength and durability. Our systems are available with dual-pane or triple-pane insulated glass, allowing you to tailor performance to meet energy efficiency goals, climate conditions, and building code requirements.

Our standard glazing includes Low-E coatings and argon gas between the panes to help improve thermal performance and comfort inside the home. A variety of decorative and specialty glass options are also available to meet the unique design and performance needs of each project. Laminated glazing can be specified in clear, bronze, gray, or green, with additional tinted interlayer options.

For projects with specialized requirements, we offer glass solutions designed for sound control (STC/OITC), high-altitude applications, coastal environments, sea turtle conservation zones, California fire zones, and hurricane-rated systems.

Not all decorative glass options are compatible with every product configuration. Please consult with your dealer or project specialist to determine the best glass package for your specific application.

Hardware

ARC windows feature a sleek, integrated hardware system built directly into the window sash to maintain clean sightlines and minimal visual obstruction. The thoughtfully engineered handle functions as both the operating mechanism and locking system, allowing the sash to be easily pushed open and pulled closed while securely locking the window when shut. This integrated design enhances everyday usability while preserving the modern aesthetic of the window. Hardware is powder coated to match the designed window color.

Screen

Screen : ARC windows feature an integrated retractable screen discreetly housed within the interior window jamb and attached directly to the window frame. The screen easily pulls across from the side when ventilation is needed, providing convenient functionality without permanently interrupting the view. When not in use, the screen retracts and remains concealed within the frame, preserving the clean lines and expansive views that define the ARC window system.

Divided Lites

Because each window is built to order, we offer extensive flexibility when it comes to divided light and grid configurations. Grid layouts can be fully customized to match the architectural intent of the project, allowing for a range of styles from modern flat bar grids to more traditional or industrial pitch profiles. Grid size, spacing, and pattern can also be tailored to achieve the desired look, giving designers and homeowners the freedom to create a truly custom window aesthetic.

Custom Shapes

ARC windows are built to order, allowing for a wide range of custom shapes and architectural configurations. From arched and round windows to unique geometric designs, our system can be tailored to fit virtually any opening. This flexibility allows architects and designers to incorporate distinctive window shapes while maintaining the sleek profiles and performance of the ARC aluminum system.
